Product Advantage
1. STRONG TENACITY NOT EASYTO PIERCE
Packaging process is not easy to be punctured and broken, avoid the useof accidental fracture and perforation of waste.
2. GOOD STRETCHABILITY
Good light transmission, keep theplants fully absorbent sun-light,good for quick healing.Strong tensile strength canreach 500% elongation to lowest cost of usage.
3. SELF-ADHESIVE
With film and film self-adhesive.self-adsorption, etc. Characteristic.winding objects are not easy tofall off.
|
Technical Parameters
Item | PVC Cable Film |
Roll Thickness | 15micron to 50micron |
Roll Width | 30mm,50mm,100mm,150mm,250mm,450mm,500mm,750mm,1000mm,2000mm or customization |
Roll Length | 50m,100m,200m,500m,1000m etc. |
Material | 100% PVC |
Tensile strength | ≥38Mpa for 19 mic,≥39Mpa for 25mic,≥40Mpa for 35mic,≥41Mpa for 50mic |
Elongation at break | ≥300% |
Angle tear strength | ≥120N/mm |
Pendulum ability | ≥0.15J for 19 mic,≥0.46J for 25mic,≥0.19J for 35mic,≥0.21J for 50mic |
Tackiness | ≥3N/cm |
Light Transmission | ≥92% for 19 mic,≥91% for 25mic,≥90% for 35mic,≥89% for 50mic |
Frog Density | ≤2.5% for 19 mic,≤2.6% for 25mic,≤2.7% for 35mic,≤2.8% for 50mic |
Package | 4&6 rolls/carton,it mostly depends on roll length,cartons on pallet |
Certificate | ROSH,ISO9001,SGS,BV |
|
Product Uses
1. Wire and cable packaging
Used to wrap wire and cable rolls. Its strong cling and wrapping properties fix the cable shape to prevent loosening, while shielding cables from dust, moisture, and scratches—facilitating storage and transportation.
2. Fruit tree graft
Applied to wrap grafted fruit tree joints. It tightly seals the connection to reduce water loss, creates a semi-enclosed environment to promote healing, and is easy to use for post-grafting protection.
3. Building materials packaging
Suitable for packaging construction supplies (e.g., hardware, pipes). It bundles loose materials to avoid collision damage during transit, while keeping them dust-free and intact for warehouse storage or on-site transfer.
4. Tire packaging
Wraps single or stacked tires. Its wrapping force secures the tire shape to prevent shifting during stacking, while protecting the tire surface from dirt and moisture for convenient storage and logistics.
|
Product Operate Guide
PVC Stretch Film Usage Guide
1. Prepare: Choose the right film size for your item; wear gloves if needed.
2. Secure the start: Attach the film’s end to the item (e.g., a cable roll or tire).
3. Wrap & stretch: Hold the film roll, stretch it moderately (avoid over-stretching), and wrap the item in overlapping layers (50% overlap recommended).
4. Reinforce key areas: For joints (e.g., grafts) or edges, wrap 2-3 extra layers for tight sealing.
5. Finish: Tear the film (or use a cutter) and press the end to secure it via self-adhesion.
It works for manual wrapping of small to medium items—adjust tension based on the product’s fragility.
|
